 Details Of Diesel Engine Automatic Portable Concrete Pump

Introduction Of Diesel Engine Automatic Portable Concrete Pump

Trailer concrete pump can be divided into concrete pump and car pump. According press structure, it can be divided into piston type, extrusion type and hydraulic diaphragm type. According to valve types, it can also be divided into the swing pipe valve , butterfly valve and gate valve.

Both trailer pump and automotive pumps are concrete transport machinery. They have the same functions, but the former requires towing vehicle for transportation and another stent pipeline, which values hundreds of thousands, and the later is the locomotive body and has the free stretch boom, no need for pipeline, which values several million dollars. Trailer pump transportation height and distance can reach hundreds of meters, which is far more than the car pump, but it requires piping, needs smaller investments but it is not flexible enough. As for the automotive pumps is flexible enough but needs higher investment.

Diesel Engine Automatic Portable Concrete Pump Application

1. The transportation for floor heating, mortar, concrete high-rise building;

2. The transportation for various construction projects in the plain concrete, fiber reinforced concrete ;

3. The transportation for the green soil in ecological environment construction;

4. The pressure grouting for various types of foundation pile .

5. The transportation for highway construction.

The reasonable match of engineer system, hydraulic system and pumping system effectively show the motor max power;

1. double pump, double circuit, open hydraulic systems, matches with each other, longer life;

2. using a large inclination smoothly hopper, effectively improve the suction efficiency;

3. Unique oil buffer allocation techniques to ensure that S pipe swing in place and extend the service life ;

4. Use the quick-change piston device to make the pistons quick and easy;

5. Adopts a proactive defense and passive defense combination of comprehensive anti-emulsion technology to achieve a zero emulsion of hydraulic system oil ;

6. Intelligent control technology matches with color touch screen and applications of high-power motor soft start device ensure grid from shock.

Parameters Of Diesel Engine Automatic Portable Concrete Pump

Model	HBTS15/8/15	HBTS-20	HBTS30/10/30	HBT40/8/45	HBT50/10/55	HBT60	HBT80
Max Theoretical Delivery Volume	7-11m³/h	15m³/h	25m³/h	35m³/h	50m³/h	60m³/h	75-80**m³/h
Max Pumping Concrete Pressure	8MPa	10MPa	10MPa	10MPa	10MPa	13MPa	18MPa
Distribution Valve Form	S-pipe valve	S-pipe valve	S-pipe valve	S-pipe valve	S-pipe valve	S-pipe valve	S-pipe valve
Concrete Conveying Cylinder Bore*Stroke	Φ120*500mm	Φ140*650mm	Φ160*750mm	Φ160*1000mm	Φ180*1000mm	Φ200*1400mm	Φ230*1800mm
Outlet Diameter	Φ125mm	Φ100mm	Φ125mm	Φ150mm	Φ150mm	Φ200mm	Φ200mm
Rated Power	15KW	30.1KW	40.1KW	45KW	55kw	75KW	110KW
Rated Speed	1480r/min	1280r/min	1280r/min	1480r/min	1480r/min	1480r/min	1480r/min
Hydraulic Circuit Form	open circuit	open circuit	open circuit	open circuit	open circuit	open circuit	open circuit
Pumping Xiyong Oil Pressure	18MPa	18MPa	18MPa	28MPa	28MPa	28MPa	40MPa
Oil Pressure Of Stirring System	8MPa	8MPa	8MPa	8MPa	8MPa	8MPa	15MPa
Hydraulic Tank Volume	70L	200L	250L	240L	240L	560L	560L
Max Conveying Vertical Distance	30m	120m	120m	120m	120m	150m	250m
Max Conveying Horizontal Distance	80m	250m	250m	250m	250m	300m	800m
Max Particles Allowed	30mm	30mm	30mm	40mm	40mm	40mm	60mm
Dimensions LW/H	2300-800-1400mm	340011001700mm	340011001700mm	380017001700mm	410017001700mm	480018001700mm	580018001900mm
Total Mass	650KG	1500KG	1500kg	2600KG	2900KG	3800KG	5000KG
