 Details Of DW Single Hydraulic Prop

Introduction Of DW Single Hydraulic Prop

DW Single hydraulic prop for seam angle is less than 25 degrees - 35 degrees inclined coal seam mining face, the adaptation of the coal seam roof and floor conditions are: roof pillars behind do not affect the recovery of base should not be too soft, prop depth is not pressed into the floor deterioration of the integrity of the base plate, or should increase the base. In the coal mining face relatively loose cannon when used on the live cylinder coating surface to take protective measures to prevent collapse. With wooden roof beams and pillars or columns used to do, you should replace the column caps cover to prevent damage to wooden beams.

Advantages Of DW Single Hydraulic Prop

1 Small size

2 Support high

3 Support reliable

4 Convenient to use and repair

5 Integrated low cost

Troubleshooting and Maintenance of DW Single Hydraulic Prop

Local scratches and hydraulic equipment hydraulic prop deformation is common problem, especially in the mouth deformation piston leakage, corrosion and other problems downhole hydraulic prop, due to equipment disassembly more difficult problems mentioned above and more traditional methods to solve difficult scene to replaced with new parts based, but the replacement cycle is long and expensive. Hydraulic prop for the latest contemporary repair methods to polymer composites based. Which has excellent adhesion and good compressive strength, not only to meet the requirements of the conditions of the production and operation process is simple, neither heat affected, coating thickness and unrestricted. While the coating itself has excellent corrosion resistance and oil self-lubricating function to ensure the wear resistance after the repair, to ensure normal production, to avoid damage to equipment components increased.

Parameter Of DW Single Hydraulic Prop

Model Item	Max height（mm）	Min.Height（mm）	Working Stroke（mm）	Rated working resistance KN	Weight （Kg）	Rated working Pressure MPa	Hydraulic pump pressure MPa	Setting load KN	Cylinder Dia. （mm）	Emulsion Liquid
DW06-350/110X	630	400	230	350	25	39.7	15-20	132-176	110	Emulsion containing 1% to 2% M10 emulsified oil
DW08-350/110X	800	490	310		28
DW10-350/110X	1000	595	405		32
DW12-350/110X	1200	700	500		36
DW14-350/110X	1400	810	590		40
DW16-350/110X	1600	920	680		44
DW18-350/110X	1800	1035	765		48
DW20-350/110X	2000	1150	850		52
DW22-350/110X	2240	1280	960		56
DW25-350/110X	2500	1430	1070		60
DW28-350/110X	2800	1600	1200		66
DW31.5-350/110X	3150	1780	1370		74
DW35-350/110X	3500	1960	1540		82
DW38-250/110X	3800	2163	1637	250	88	28.3
DW40-250/110X	4000	2224	1780		96
DW42-250/110X	4200	2330	1880		100
DW45-250/110X	4500	2480	2020		110
